3-Zone Remote Control Module MONO
This product is already in your cart: 0 pcs View cart
Quantity discount
| Quantity | Price |
|---|---|
| 1 - 9 | 3,80 € |
| 10 - 19 | 3,30 € |
| 20+ | 3,10 € |
Already a wholesale customer? Log in to see your prices
The PUSH2-3 three-zone MONO module is a remote control unit that allows for quick conversion of a traditional push switch into a RF remote controller for other MIBOXER products. PUSH2-3 is battery power device and operates within a safe voltage range of 3V, enabling installation even by individuals without specialized knowledge or qualifications. PUSH2-3 does not interfere with the electrical installation, remaining completely independent, and the CR2032 battery allows for up to 3 years of maintenance-free operation under standard use. Witch PUSH2-3 you have ability to control brightness.
Connection diagram
Requires use with PUSH switch
| Product Name: | 2.4GHz Wireless Dimming (3-Zone) |
|---|---|
| Model No.: | PUSH2-3 |
| Input Voltage: | 3V (CR2032*1PC) |
| Transmitting Power: | 6dBm |
| RF: | 2.4GHz |
| Control Distance: | 30m |
| IP Rating: | IP20 |
| Working Temperature: | -10~40℃ |
| Standby Power Consumption: | <3μA |
| Dimming Grayscale: | 4096 Levels |
|---|---|
| Dimming Range: | 0.1%-100% |
| EMC Standard (EMC): | ETSI EN 301 489-1 V2.2.3 ETSI EN 301 489-3 V2.1.1 |
| Safety Standard (LVD): | EN 61347-1：2015+A1: 2018 EN 61347-2-11: 2001+A1:2019 |
| Radio Equipment (RED): | ETSI EN 300 440 V2.2.1 |
| Certification: | CE, EMC, RED |
